The Axion 2 XG30 Compact is a thermal imaging monocular featuring a high-resolution 640 × 480 sensor with a 12 µm pixel pitch and a sensor NETD of less than 25 mK. The compact thermal imaging system is designed to provide detailed heat-signature visualization across varying environmental conditions.

Equipped with an F30 / 1.2 objective lens, the Axion 2 XG30 Compact offers a magnification range of 2×–16×. Its listed field of view is 14.6°, with a detection range of up to 1,400 yards.

Reinforced Magnesium Alloy Housing

The reinforced magnesium alloy housing combines durability with a lightweight design. It helps protect the internal components from shocks, drops, moisture, and temperature variations. The metal housing also assists with heat dissipation from the electronics, supporting consistent operation during extended use.

Dual-Band Wi-Fi Connectivity

The Axion 2 supports both 2.4 GHz and 5 GHz Wi-Fi for smartphone connectivity. The 5 GHz band provides higher bandwidth and faster data transfer, along with improved resistance to interference and connection stability in supported environments.

High-Resolution Thermal Sensor

The 640 × 480 / 12 µm thermal sensor provides detailed thermal imagery for scanning and identifying heat sources across a variety of conditions.

Key Specifications

• Model: Axion 2 XG30 Compact
• Sensor: 640 × 480 pixels @ 12 µm
• Sensor NETD: <25 mK
• Objective Lens: F30 / 1.2
• Magnification: 2×–16×
• Field of View: 14.6°
• Detection Range: Up to 1,400 yards
• Housing: Reinforced magnesium alloy
• Wi-Fi: 2.4 GHz / 5 GHz
